Product Description:
The VMC850 CNC Vertical Machining Center offers a powerful Fanuc control system, maximum spindle speed of
8000 rpm and Z-axis travel of 500 mm. It is designed to provide
heavy-duty cutting capabilities for a wide range of materials. The
VMC850 has a tool changer capacity of 16/24, and is capable of
delivering high-speed, high-precision machining for a range of
complex parts. It features a robust construction designed to
withstand tough operating conditions and a large working area for
efficient production. This highly efficient CNC Vertical Machining
Center is ideal for a range of machining applications, from
aerospace to automotive, and is sure to be a valuable asset to any
shop.
Features:
- Product Name: CNC Vertical Machining Center
- Repeat positional accuracy: ±0.005mm
- Machine Weight (Kg): 5300kg
- Max loading weight on worktable: 600kg
- Control Type: CNC
- Model: VMC850
Applications:
It is widely used to produce the auto spare parts, medical
treatment instrument and any kind of injection mould, blowing
mould, die-casting mould, car LED mould, toy mould and precise
mould and o on.Large steel molds are the first products requiring
large cutting amount and fast processing speed. It is applicable to
the processing of plastic mold industry, automobile tire industry,
hardware industry, toy industry, handicrafts, fine stamping die,
bronzing die, high-frequency die, embossing wheel die, die-casting
die and graphite electrode. It is the best choice for mold
manufacturing industry and parts processing.
Technical Parameters:
| Product Attribute | Technical Parameter |
|---|
| Control System | FANUC |
| X-Axis Travel | 800mm |
| Tool Changer Capacity | 16/24 |
| Y-Axis Travel | 500mm |
| Max loading weight on worktable | 600kg |
| Model | VMC850 |
| Machine Weight (Kg) | 5300kg |
| Size of worktable (length width) | 1000X500 |
| Repeat positional accuracy | ±0.005mm |
| Z-Axis Travel | 500mm |
| Coolant System | FANUC |
Customization:
We provide custom services for CNC Vertical Machining Center with Fanuc control system. Our VMC850 model is capable of Max loading weight on worktable 600kg, and it has the machine weight 5300kg. The positional accuracy is ±0.01mm, and the spindle center to Z-axis guide surface is 552mm. Choose our CNC Vertical Machining Center for the highest
quality machining.
Support and Services:
We provide technical support and services for CNC Vertical
Machining Center. Our technical support team is available 24/7 and
is comprised of experienced professionals who can help you with
installation, troubleshooting, and ongoing maintenance. We also
provide on-site service and training to ensure that you are getting
the most out of your machine. With our comprehensive after-sales
service, you can rest assured that your CNC Vertical Machining
Center is running optimally and efficiently.
Packing and Shipping:
Packaging and Shipping for CNC Vertical Machining Center:
- The CNC Vertical Machining Center is securely packaged in a wooden
crate.
- The crate is placed on a pallet and safely secured with straps.
- The pallet is then shrink-wrapped to protect the crate from dirt
and moisture.
- The pallet is then loaded onto a truck for delivery to the
customer.
FAQ:
Q: What is the Brand Name of the CNC Vertical Machining Center?
A: The Brand Name of the CNC Vertical Machining Center is HR.
Q: What is the Model Number of the CNC Vertical Machining Center?
A: The Model Number of the CNC Vertical Machining Center is VMC850.
Q: What is the Place of Origin of the CNC Vertical Machining
Center?
A: The Place of Origin of the CNC Vertical Machining Center is
China.
Q: What is the cutting speed of the CNC Vertical Machining Center?
A: The cutting speed of the CNC Vertical Machining Center can reach
up to 24m/min.
Q: What is the feed speed of the CNC Vertical Machining Center?
A: The feed speed of the CNC Vertical Machining Center can reach up
to 30m/min.
